M3 UL20X
5" Block type Ultra Rugged Computer
  • - Android 8.1 Oreo
    - 2.2GHz Octacore CPU
    - 2D imager / Long range scanner
    - 5" Full Touch FHD (Gorilla® Glass)
    - IEEE 802.11 a/b/g/n/ac
    - IP67 Sealing, 2.0m Drop
    - WWAN: GSM, WCDMA, TDD-LTE, FDD-LTE
  • 5“ LCD
  • Logn Range
  • 25° Angle

  • tabbutton1

    • Android 8.1 Oreo
      The optimized Android 8.1 platform enhances processing time. It provides various functions for enterprise.
    • 2.2GHz Octa-core Processor
      M3 UL20X has a 2.2GHz 8 core AP, which has strength in calculation speed and memory reading and writing.
    • 5 inch Block type Full HD Display (World-first)
      With large high visibility color display, Full HD screen enables stable business. UL20X offers crystal 5.0 Inch Corning® Gorilla® Glass on display.
    • 2D, Long range Scanner
      With 2D imager and integrated Long range scanner, UL20 provides real-time data capture and automatic data processing.
    • Angled Scanner (25 degrees)
      Tilted scanner helps comfortable aiming without bending wrist while looking at front screen.
    • 16MP (rear) Auto Focus Camera
      High resolution and auto focused functionality capture clear images of product and/or documentation.
    • IP67 sealing
      M3 UL20 series withstands drops from 2.0m and protects under IP67 against dust and water.
    • NFC RFID
      UL20X supports near-field communication(NFC).
    • Wireless WAN
      Whether indoors or in the field, UL20X provides the fastest, reliable wireless connections with support for the fastest Wi-Fi and 4G LTE, enabling workers to stay connected from anywhere.

  • tabbutton1

      Physical Characteristics
      DIMENSION (W x H x D)
      Millimeters 88.7 x 244.75 x 46.19
      Inches 3.49 x 9.64 x 1.82
      WEIGHT (incl. battery)
      Grams 580
      Ounces 20.46
      DISPLAY
      Size 5"
      Type FHD
      Pixels 1920 x 1080
      BATTERY
      Type Standard
      Cell Li-ion
      Power 3.6 V 6,700 mAh
      Performance Characteristics
      MULTI-PROCESSOR
      CPU 2.2 GHz Octa-core
      Radio
      OS
      Android 8.1 Oreo
      MEMORY
      RAM 4 GB
      ROM 32 GB
      Card Slot 2 SIM, Micro SD
      USB INTERFACE
      Host USB 2.0 (A type) via cradle
      Client USB 2.0 (C type) via cradle
      User Environment
      TEMPERATURE
      Operating -20 ℃ to 60 ℃ (-4 °F to 140 °F)
      Storing -30 ℃ to 80 ℃ (-22 °F to 176 °F)
      HUMIDITY
      0％ to 95％ non-condensing
      Tumble Test
      2,000 Cycle 3.2 ft / 1.0 m (4,000 drops)
      Drop Test
      6.4 ft / 2.0 m
      IP Rating
      IP67
      Wireless Radio Options
      WWAN
      2G Network
      (GSM/GPRS/EDGE)      		 GSM : B3, B5, B8
      3G Network
      (UMTS/HSPA+)      		 WCDMA : B1, B5, B8
      4G Network
      (FDD LTE)      		 TDD-LTE : B38, B40, B41 FDD-LTE : B1, B3, B5, B7, B8, B20
      WLAN
      Standard IEEE 802.11
      Bandwidth a/b/g/n/ac
      Security
      BLUETOOTH
      Class Class II
      Version V4.1 LE
      RFID
      Frequency NFC (13.56MHz)
      Standard ISO 14443 A / B, ISO 15693
      GPS
      A-GPS, GLONASS, Beidou, Galileo
      General Options
      SCANNER
      1D N/A
      2D O
      Long range O
      CAMERA
      Pixels 16.0 MP (REAR) LED Flash
      Focus Auto Focus
      KEYPAD
      Alpha-Numeric 35, 28, 53 Key
      Qwerty
      Azerty

      * The contents of this specification were made based on the "current state" of the product, and this specification may change without notice.
