- M3 SL10-N
- Truly Handy and Pocketable Mobile Computer
-
- - Android 8.1 Oreo
- 1.44GHz Quad-core CPU
- 2D imager
- 5" HD LCD
- IEEE 802.11 a/b/g/n
- IP65 Sealing, 1.2m Drop (1.5m with Boots)
- Li_Polymer Battery 4,000mAh
- - Android 8.1 Oreo
-
-
M3 SL10-N
-
5“ LCD
-
Large Battery
-
-
-
tabbutton1
-
tabbutton1
- Physical Characteristics
-
DIMENSION (W x H x D) Millimeters 156 x 74 x 17 Inches 6.14 x 2.91 x 0.67 WEIGHT (incl. battery) Grams 260 Ounces 9.17 DISPLAY Size 5" Type HD Pixels 1280 X 720 BATTERY Type Standard Cell Li_ion Power 4,000 mAh - Performance Characteristics
-
MULTI-PROCESSOR CPU 1.44 GHz Quad-core Radio OS Android 8.1 Oreo MEMORY RAM 2 GB ROM 16 GB Card Slot 1 SIM, Micro SD USB INTERFACE Host Client Micro USB 2.0 - User Environment
-
TEMPERATURE Operating -20 ℃ to 50 ℃ (-4 °F to 122 °F) Storing -30 ℃ to 70 ℃ (-22 °F to 158 °F) HUMIDITY 95% non-condensing Tumble Test - Drop Test 1.2M / 1.5M (with Boots) IP Rating IP65 - Wireless Radio Options
-
WWAN 2G Network
(GSM/GPRS/EDGE)GSM 2/3/5/8 3G Network
(UMTS/HSPA+)TD-SCDMA 34/39 WCDMA 1/2/5/8 4G Network
(FDD LTE)LTE 1/2/3/4/7/17/20/38/39/40/41 WLAN Standard IEEE 802.11 Bandwidth a/b/g/n Security BLUETOOTH Class Class I Version V4.0 BLE RFID Frequency NFC (13.56MHz) Standard ISO 14443 A / B, ISO 15693 GPS AGPS, GLONASS - General Options
-
SCANNER 1D 2D O Long range CAMERA Pixels 8M Pixels (Rear) / 2M Pixels (Front) Focus Auto Focus KEYPAD Alpha-Numeric Front 4 Keys Qwerty Azerty
* The contents of this specification were made based on the "current state" of the product, and this specification may change without notice.
-
