View Point
A compact mobile computer with a proven track record of reliability among multiple users.
The M3 Mobile’s best-selling model features a lightweight design at 250g, a 5.5-inch touchscreen, and Back, Home, and Menu buttons.Its robust IP67-rated construction ensures long-lasting durability across a variety of industrial environments.
With Wi-Fi 5 and 4G connectivity, uninterrupted wireless communication is maintained, while the 5,000mAh battery with hot-swap capability enables extended, reliable operation.
Additionally, users can choose between 4/64GB or 8/128GB memory (optional), and the MicroSD slot supports expansion up to 1TB, providing ample data storage capacity.
Highlights
-
Lightweight and highly portable
With its lightweight 250g design including the battery and a smartphone-level compact form factor, the device can be easily stored in a pocket during two-handed tasks and quickly retrieved when needed, delivering exceptional portability and mobility. -
Proven Reliability and Durability Trusted by Diverse Users
Since its release, this best-selling model has been consistently deployed across various industrial environments, earning a strong reputation for reliable performance. It features IP67-rated dust and water resistance and withstands drops of up to 1.8 meters with a protective boot, as well as more than 1,000 tumble cycles. Additionally, it meets the U.S. Department of Defense durability standard, MIL-STD-810G, ensuring dependable robustness even in extreme working conditions. -
5.5-inch Display with Efficient Navigation Keys
The 5.5-inch display, combined with Back, Home, and Menu navigation keys, enables intuitive data viewing and effortless device operation. -
Reliable Connectivity
With support for Wi-Fi 5, 4G, Bluetooth 5.0, and dual nano SIMs, the device provides wide-range, fast, and stable connectivity without interruption. -
Up to 12 Hours of Non-Stop Operation
Equipped with a 5000mAh battery, the device can be used for up to 12 hours without the need for replacement. With hot-swap capability, you can replace the battery without interrupting or resetting ongoing tasks. -
Memory Options and 1TB Expandable Slot Tailored to User Needs
Depending on data processing and multitasking requirements, users can choose between 4/64GB or 8/128GB memory configurations. The expandable slot supports up to 1TB, allowing seamless management of large data volumes and multiple applications without storage limitations. -
Clear Image and Video Capture
With a 5MP front camera and a 13MP rear camera, the device enables clear image and video capture in any environment.
Specification
| Size | ⓦ 72.7 x ⓗ 156.8 x ⓓ 17.55 mm |
|---|---|
| Weight | 250g |
| Display | 5.5 Inch HD |
| Memory | 4/64 GB, 8/128GB(Option) |
| CPU | 2.0 GHz Octa-core |
| Operating System | Android 13 to 15 |
| Data Capture | 2D Imager - E5, SE4710(Option) |
| WWAN | Support VoLTE LTE FDD: 700/800/850/900/1700/1800/1900/2100/2600 (1/2/3/4/5/7/8/19/20/28); LTE TDD: 1600/2300/2500 (38/40/41); UMTS/HSDPA/HSPA+: 850/900/1800/1900/2100(1/2/3/4/5/8); GSM/GPRS/EDGE: 850/900/1800/1900 (2/3/5/8); |
| WLAN | IEEE 802.11 a/b/g/n/ac/d/e/h/i/j/k/r/v, IPv4, IPv6, 1X1 MU-MIMO |
| Battery | 5000mAh Hot-Swap Support |
| Tumble Test | 1M/1,000times (With Boots), 0.5M/2,000times (Without Boots) |
| Drop Test | 1.8M (With Boots), 1.5M (Without Boots) drops to concrele across the operating temperature range per MIL-STD-810G |
| Sealing | IP 67 |
